Wireless 2.4G DMX512 Transmitter Receiver
2.4G wireless DMX512
Type: Independent Installation
Size: 120 x 30 x 30 mm (with antenna)
Weight: 100g
CPU: 32-bit ARM core
Communication distance: 1000 meters
Working frequency band: 2.400-2.4835GHz, ISM, 126 frequency bands
Modulation method: GFSK
Maximum transmission power: 23dBm
Receiver sensitivity: -94dBm DMX signal interface RS485
Working temperature: -40~85 ° C, 5~95% RH humidity
Storage temperature: -65~150 ° C, 5~95% RH humidity
Power input: 5 VDC, ± 5%
Power consumption: 500 mA@5 VDC max.
Automatic restart timer: built-in WDT
Warranty period: 1 year
